Spot Welding Machines‎

Spot Welding Machines‎
Spot Welding Machines‎
Product Code : SWM 19
Brand Name : VIRDI ELECTRIC WORKS PVT. LTD
Trade Information
  • Unit of Measure
  • Unit/Units
  • Payment Terms
  • Cheque, Others
  • Supply Ability
  • 150-200 units per month.
  • Delivery Time
  • Week
  • Packaging Details
  • Customized.
  • Main Domestic Market
  • All India
  • Certifications
  • ISO, NSIC,MSME
Product Description

Spot Welding Machines

We offer a wide collection of Spot Welding Machines‎ which is sturdy and is of robust construction. This Spot Welder is very easy to maintain and highly appreciated for its features like durable, reliable and high performance. We manufacture this Spot Welder using high grade raw materials are used along with extensive techniques. This Spot Welder is designed to perfection and is available in various forms as per client requirements. Spot Welder is easy to use with excellent performance and ranged at a reasonable price.

Products Features

  • High solder capability is achieved with particular type of transformer.
  • Facility to fuse thick material at little speed using small length arms.
  • In physically operated instruments at low speed using short length arms.
  • Easy to maintain.

Construction:
The unit is of strong construction, robust, intense, rigidly durable welded steel structure. It unites a dense streamlined look with utmost confrontation to automatic deflection. The transformer enclosed in the main frame and is effortlessly available, for examination.

--------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------
Welding Transformer:
Fabricated from superior grade materials of copper strips and sections, water cooled with class ‘F’ padding with standing constant temperature rise of 140’C. The coils are saturated and stifling.

Current Control:
By tap method with 8 tap alterations on principal of the main transformer having current control from 50% - 100% in 8 steps.

Cooling system:
By tap link method with 8 tap modifications on primary of the main transformer having current control Electrodes, Electrode holders, Arms, Transformer are all water cooled with one single water-cooling circuit.

Electrode Control System :

Upper electrode is activated by foot lever or by air cylinder. The electrode force can effortlessly be calculated in both systems. Air system is offered with estimate and manual system with regulated spring. All air accessories such as filter, lubricator, regulator, gauge, solenoid valve and speed valve are integrated.

Maximum Operating Speed:
Machine is automatically capable of attaining 60 spots per minute.

Technical Specification:

Machine Model No. UNITS VSM-7.5 VSM-10 VSM-15 VSM-20
KVA @50% Duty Cycle KVA 7.5 10 15 20
Rated Input Voltage V 230/415V 230/451V 230/415V 230/415V
Transformer Cooling Water Water Water Water Water
Water Consumption LPM 5 5 8 10
Arms-Diameter (mm) 40 45 51 64
Main Supply Cable Size (mm2) 10/7 12/8 16/10 16/25
Cu / Al
Main Disconnection [Amps] 25/15 30/20 60/35 60/55
Switch / fuse
Current Taps Nos. 8 8 8 8
Over All Size
{Approximately}[mm] D= 410 460 460 510
  W= 250 280 280 310
  H= 1020 1150 1300 140
